TRI – Automated Optical Inspection (AOI) – TR7710


The economical customizable TR7710 combines a precise high resolution camera system and TRI&’s exclusive multi-phase lighting to capture detailed PCB panel images. New optical solution offers increased DOF range for tall components with optional high clearance. TRI Series III AOI-compatible inspection software combines excellent defect detection and easy smart CAD-based programming into a cost effective, customizable AOI solution designed to fit any budget.

• Economical and highly customizable inline AOI solution
• 6.5 Mpix high speed color camera
• NPI-optimized easy programming interface wizard
• Stop-and-Go inspection with large depth of field (DOF)
• 10 µm or 12.5 µm optical resolution
